openlayers 加载瓦片详解一：加载瓦片的算法类（转自studypower的专栏）

标签：
Html/CSS JavaScript

图片描述

我们在客户端看到的瓦片其实是一个图片列表 也就是上面的grid 类 ，每张图片都是通过http从后来请求过来的图片也就是方法getURL（bound），
每张图片都有自己的url 也就是他的请求地址，而且grid的列表的每个单元格都有边框也就是bound，那要获取每个单元格中正确的图片都是通过bound来计算而获取到相应的图片，如想要加载自己瓦片就需要重写grid中的getURL(bound)方法，这也就是最下排6个不同类型的瓦片根据自己的瓦片特点及地图服务的特点编写的类，如果你有自己的瓦片却跟上面的几种都不相同也不相似，那你可以选择重写grid类，如果你的瓦片操作跟下面的6中服务相同或者类似，那可以根据自己工作考虑重写那面6个类中的其中某一个中的getURL(bound)的方法。在计算的过程中能涉及到多个参数将在下篇来详细介绍，在这给几个重写getURL(bound)的例子, 第一个例子是网上的不过在工作中验证过，绝对可用，写的还不错给大家个参考。

1、重写grid类中的getURL(bound)方法加载本地图片(天地图)

OpenLayers.Layer.TiandituLayer = OpenLayers.Class(OpenLayers.Layer.Grid,
        {

            TileType : null,
            mirrorUrls : null,
            topLevel : null,
            bottomLevel : null,
            topLevelIndex : 0,
            bottomLevelIndex : 20,
            topTileFromX : -180,
            topTileFromY : 90,
            topTileToX : 180,
            topTileToY : -90,
            isBaseLayer : true,
            initialize : function(name, url, options) {

                options.topLevel = options.topLevel ? options.topLevel
                        : this.topLevelIndex;
                options.bottomLevel = options.bottomLevel ? options.bottomLevel
                        : this.bottomLevelIndex;
                options.maxResolution = this
                        .getResolutionForLevel(options.topLevel);
                options.minResolution = this
                        .getResolutionForLevel(options.bottomLevel);
                var newArguments = [ name, url, {}, options ];
                OpenLayers.Layer.Grid.prototype.initialize.apply(this,
                        newArguments);
            },

            clone : function(obj) {

                if (obj == null) {
                    obj = new OpenLayers.Layer.TDTLayer(this.name, this.url,
                            this.options);
                }

                obj = OpenLayers.Layer.Grid.prototype.clone
                        .apply(this, [ obj ]);

                return obj;
            },

            getURL : function(bounds) {
                var level = this.getLevelForResolution(this.map.getResolution());
                var coef = 360 / Math.pow(2, level);
                var Row = this.topTileFromX < this.topTileToX ? Math.round((bounds.left - this.topTileFromX) / coef) : Math.round((this.topTileFromX - bounds.right) / coef);
                var Col = this.topTileFromY < this.topTileToY ? Math.round((bounds.bottom - this.topTileFromY) / coef): Math.round((this.topTileFromY - bounds.top) / coef);

                var type = this.TileType;
                if (type == "EMap") {
                    if (level >= 2 && level <= 10) {
                        type = "A0512_EMap";
                    } else if (level == 11 || level == 12) {
                        type = "B0627_EMap1112";
                    } else if (level >= 13 && level <= 18) {
                        type = "siwei0608";
                    }
                }else if(type=="RMap"){
                    if (level >= 2 && level <= 7) {
                        type = "sbsm0210";
                    } else if (level >= 8 && level <= 10) {
                        type = "sbsm0210";
                    } else if (level >= 11 && level <= 14) {
                        type = "e11";
                    }else if (level >= 15 && level <= 18) {
                        type = "sbsm1518";
                    }
                }

                var url = this.url;

                if (this.mirrorUrls != null) {
                    url = this.selectUrl(Row, this.mirrorUrls);
                }

                return this.getFullRequestString({
                    T : type,
                    X : Row,
                    Y : Col,
                    L : level
                }, url);
            },
            selectUrl : function(a, b) {
                return b[a % b.length]
            },
            getLevelForResolution : function(res) {
                var ratio = this.getMaxResolution() / res;
                if (ratio < 1)
                    return 0;
                for ( var level = 0; ratio / 2 >= 1;) {
                    level++;
                    ratio /= 2;
                }
                return level;
            },
            getResolutionForLevel : function(level) {
                return 360 / 256 / Math.pow(2, level);
            },
            getMaxResolution : function() {
                return this.getResolutionForLevel(this.topLevelIndex)
            },
            getMinResolution : function() {
                return this.getResolutionForLevel(this.bottomLevelIndex)
            },
            addTile : function(bounds, position) {
                var url = this.getURL(bounds);
                return new OpenLayers.Tile.Image(this, position, bounds, url,
                        this.tileSize);
            },

            CLASS_NAME : "OpenLayers.Layer.TiandituLayer"
        });

测试页面

view plain copy print?
<!DOCTYPE html>
<html>
  <head>
    <meta http-equiv="Content-Type" content="text/html; charset=utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0, maximum-scale=1.0, user-scalable=0">
    <meta name="apple-mobile-web-app-capable" content="yes">
    <title>OpenLayers Tiled Map Service Example</title>
    <link rel="stylesheet" href="../theme/default/style.css" type="text/css">
    <link rel="stylesheet" href="style.css" type="text/css">
    <script type="text/javascript">

        var map, layer;

        function init(){
            var extent = new OpenLayers.Bounds(-180.0, -90.0, 180.0, 90.0);
            var tempScales = [295497593.05875003,147748796.52937502,73874398.264687508,36937199.132343754,18468599.566171877];
            var mapOptions = {
                maxExtent: extent
            };
            var options= {
                mapType:"EMap",
                topLevel: 3,
                bottomLevel: 20

            };
            map = new OpenLayers.Map("map",mapOptions);

            layer = new OpenLayers.Layer.TiandituLayer("qincy", "http://tile0.tianditu.com/DataServer",options);
            map.addLayer(layer);
            map.addControls([new OpenLayers.Control.MousePosition()]);

            map.setCenter(new OpenLayers.LonLat(106,39), 3);

        }
    </script>
  </head>
  <body onload="init()">
    <div id="map" style="width:1000px;height:500px"></div>
  </body>
</html>

2、重写TileCache类加载本地图片。
/**

  • 对自定义规则切割的图片进行拼装的类
    */
SimpleTileCache=OpenLayers.Class(OpenLayers.Layer.TileCache,{
    initialize:function(name,url,options){
        var tempoptions = OpenLayers.Util.extend(
{'format': 'image/png',isBaseLayer:true},options);
        OpenLayers.Layer.TileCache.prototype.initialize.apply(this,[name, url, {}, tempoptions]);
        this.extension = this.format.split('/')[1].toLowerCase();
        this.extension = (this.extension == 'jpg') ? 'jpeg' : this.extension;
        this.transitionEffect="resize";
        this.buffer=2;
    },
    /**
     *   按地图引擎切图规则实现的拼接方式
     */
    getURL: function(bounds) {
        var res   = this.map.getResolution();
        var bbox  = this.map.getMaxExtent();
        var size  = this.tileSize;
        //计算列号
        var tileX = Math.round((bounds.left - bbox.left) / (res * size.w));
           //计算行号
        var tileY = Math.round((bbox.top-bounds.top) / (res * size.h));
        //当前的等级
        var tileZ = this.map.zoom;
        if(tileX<0) tileX=tileX+Math.round(bbox.getWidth()/bounds.getWidth());
        if(tileY<0)  tileY=tileY+Math.round(bbox.getHeight()/bounds.getHeight());
        return  this.getTilePic(tileX,tileY,tileZ);
    },
    getTilePic: function(tileX,tileY,tileZ){
        var dir = '';
        if(tileZ > 6) {
            var delta       = Math.pow(2,tileZ-5);
            var rowDir   = 'R'+ Math.floor(tileY /delta);
            var colDir   = 'C'+Math.floor(tileX /delta);
            dir      = tileZ  + "/" + rowDir + "/" + colDir + "/";
        } else {
            dir= tileZ + '/';
        }
        var tileNo  = tileZ + "-" + tileX + "-" + tileY;
        var sUrl = this.url + dir + tileNo + '.png';
        return sUrl;
    },
    clone: function (obj) {
        if (obj == null) {
        obj = new SimpleTileCache(this.name,this.url,this.options);
        }
        obj = OpenLayers.Layer.TileCache.prototype.clone.apply(this, [obj]);
        return obj;
    },
    CLASS_NAME: "SimpleTileCache"
});

3、直接修改TileCache类中的getURL方法

修改后 的 TileCache.js

OpenLayers.Layer.TileCache = OpenLayers.Class(OpenLayers.Layer.Grid, {

    isBaseLayer: true,

    format: 'image/png',

    serverResolutions: null,

    initialize: function(name, url, layername, options) {
        this.layername = layername;
        OpenLayers.Layer.Grid.prototype.initialize.apply(this,
                                                         [name, url, {}, options]);
        this.extension = this.format.split('/')[1].toLowerCase();
        this.extension = (this.extension == 'jpg') ? 'jpeg' : this.extension;
    },

    clone: function (obj) {

        if (obj == null) {
            obj = new OpenLayers.Layer.TileCache(this.name,
                                                 this.url,
                                                 this.layername,
                                                 this.getOptions());
        }

        //get all additions from superclasses
        obj = OpenLayers.Layer.Grid.prototype.clone.apply(this, [obj]);

        // copy/set any non-init, non-simple values here

        return obj;
    },

     getURL: function(bounds) {
        var res = this.map.getResolution();
        var x = Math.round ((bounds.left - this.maxExtent.left) / (res * this.tileSize.w));
        var y = Math.round ((this.maxExtent.top - bounds.top) / (res * this.tileSize.h));
        var z = this.map.getZoom();
        var path =z+9+ "/" + x + "/" + y + "." + this.type;
        var url = this.url;
        if (url instanceof Array) {
            url = this.selectUrl(path, url);
        }
        //我用resin 发布的地图瓦片的位置
        url="http://192.168.0.90:88/roadmap2/"+path;
        return url
    },

    /*getURL: function(bounds) {
        var res = this.getServerResolution();
        var bbox = this.maxExtent;
        var size = this.tileSize;
        var tileX = Math.round((bounds.left - bbox.left) / (res * size.w));
        var tileY = Math.round((bounds.bottom - bbox.bottom) / (res * size.h));
        var tileZ = this.serverResolutions != null ?
            OpenLayers.Util.indexOf(this.serverResolutions, res) :
            this.map.getZoom();

        var components = [
            this.layername,
            OpenLayers.Number.zeroPad(tileZ, 2),
            OpenLayers.Number.zeroPad(parseInt(tileX / 1000000), 3),
            OpenLayers.Number.zeroPad((parseInt(tileX / 1000) % 1000), 3),
            OpenLayers.Number.zeroPad((parseInt(tileX) % 1000), 3),
            OpenLayers.Number.zeroPad(parseInt(tileY / 1000000), 3),
            OpenLayers.Number.zeroPad((parseInt(tileY / 1000) % 1000), 3),
            OpenLayers.Number.zeroPad((parseInt(tileY) % 1000), 3) + '.' + this.extension
        ];
        var path = components.join('/');
        var url = this.url;
        if (OpenLayers.Util.isArray(url)) {
            url = this.selectUrl(path, url);
        }
        url = (url.charAt(url.length - 1) == '/') ? url : url + '/'; //url+path
        //alert(url+path);
        return "http://192.168.0.90:88/roadmap/1/0/0.png"
    },*/

    CLASS_NAME: "OpenLayers.Layer.TileCache"
});

测试页面

<!DOCTYPE html>
<html>
  <head>
    <meta http-equiv="Content-Type" content="text/html; charset=utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0, maximum-scale=1.0, user-scalable=0">
    <meta name="apple-mobile-web-app-capable" content="yes">
    <title>OpenLayers TileCache Example</title>
     <link rel="stylesheet" href="../theme/default/style.css" type="text/css">
        <link rel="stylesheet" href="style.css" type="text/css">
    <script type="text/javascript">
    //alert("adsf");
       var proj='EPSG:900913'; //900913
        var map, layer;
        var proj2 = new OpenLayers.Projection("EPSG:4326");
        var agsTileOrigin = new OpenLayers.LonLat(-180,85);
        agsTileOrigin.transform(proj2, new OpenLayers.Projection("EPSG:900913"));
        //alert(agsTileOrigin.);
        var mapExtent = new OpenLayers.Bounds(-20037508.34,-20037508.34,20037508.34,20037508.34);
        function init(){

        //添加编辑图层 图层名称为editLayer
            var EditLayer=new OpenLayers.Layer.Vector("EidtLayer");
        //添加地图
            map = new OpenLayers.Map( 'map', {
                numZoomLevels:3,                             //缩放级别
                resolutions:[305.7481,152.8741,76.437],      //分别率  单位是米
                controls:[
                        new OpenLayers.Control.EditingToolbar(EditLayer), //添加编辑控件
                        new OpenLayers.Control.Navigation(),
                        new OpenLayers.Control.PanZoomBar(),
                        new OpenLayers.Control.LayerSwitcher({'ascending':false}),
                        new OpenLayers.Control.Permalink(),
                        new OpenLayers.Control.ScaleLine(),
                        new OpenLayers.Control.Permalink('permalink'),
                        new OpenLayers.Control.MousePosition(),
                        new OpenLayers.Control.OverviewMap(),
                        new OpenLayers.Control.KeyboardDefaults()
                        ]
            });
            layer = new OpenLayers.Layer.TileCache("TileCache Layer",
                "http://c0.tilecache.osgeo.org/wms-c/cache/",
                "basic",
                {
                 serverResolutions:[305.7481,152.8741,76.437],
                                        projection:proj,
                                        type:'png'
                }
            );

            map.addLayers([layer, EditLayer]);
            var  lob_ll=new OpenLayers.LonLat(121.34457, 31.329235);
            map.setCenter(lob_ll.transform(proj2, new OpenLayers.Projection("EPSG:900913")), 0);
        }
    </script>
    <style type="text/css">
    html,body{width:100%;height:100%;margin:0;}
    </style>
  </head>
  <body onload="init()">
    <div id="map"  class="smallmap"  style="width:100%; height:100%; backround-color:Red;"></div>
  </body>
</html>
