有需要做电商类app的童鞋可以看看, 首先先看看效果实现
本项目使用的第三方框架:
加载网络图片使用的 Fresco
头部的商品图轮播 ConvenientBanner
导航栏切换 PagerSlidingTabStrip
github地址
效果图
由于代码量过多, 就不一一讲解只介绍几个核心的自定义控件)
不想看的童鞋可以下载apk或者在github上下载源码使用
最外层的布局文件
ItemWebView是
SlideDetailsLayout的子View (SlideDetailsLayout代码太多, 放到了最后)功能为显示商品简介的
Webview防止往上滑动时会直接滑动到第一个
View实现滑动到
WebView顶部时, 让父控件重新获得触摸事件
/**
* 商品详情页底部的webview
*/public class ItemWebView extends WebView { public float oldY; private int t; private float oldX; public ItemWebView(Context context) { super(context);
} public ItemWebView(Context context, AttributeSet attrs) { super(context, attrs);
} public ItemWebView(Context context, AttributeSet attrs, int defStyleAttr) { super(context, attrs, defStyleAttr);
} @Override
public boolean onTouchEvent(MotionEvent ev) { switch (ev.getAction()) { case MotionEvent.ACTION_MOVE: float Y = ev.getY(); float Ys = Y - oldY; float X = ev.getX(); //滑动到顶部让父控件重新获得触摸事件
if (Ys > 0 && t == 0) {
getParent().getParent().requestDisallowInterceptTouchEvent(false);
} break; case MotionEvent.ACTION_DOWN:
getParent().getParent().requestDisallowInterceptTouchEvent(true);
oldY = ev.getY();
oldX = ev.getX(); break; case MotionEvent.ACTION_UP:
getParent().getParent().requestDisallowInterceptTouchEvent(true); break; default: break;
} return super.onTouchEvent(ev);
} @Override
protected void onScrollChanged(int l, int t, int oldl, int oldt) { this.t = t; super.onScrollChanged(l, t, oldl, oldt);
}
}ItemListView 也是
SlideDetailsLayout的子View跟
ItemWebView功能大致一样当然这里不只是
ListView可以, 其他的控件都可以写成这样来适配SlideDetailsLayout的滑动功能
/**
* 商品详情页底部的ListView
*/public class ItemListView extends ListView implements AbsListView.OnScrollListener { private float oldX, oldY; private int currentPosition; public ItemListView(Context context) { super(context);
setOnScrollListener(this);
} public ItemListView(Context context, AttributeSet attrs) { super(context, attrs);
setOnScrollListener(this);
} public ItemListView(Context context, AttributeSet attrs, int defStyleAttr) { super(context, attrs, defStyleAttr);
setOnScrollListener(this);
} @Override
public boolean onTouchEvent(MotionEvent ev) { switch (ev.getAction()) { case MotionEvent.ACTION_MOVE: float Y = ev.getY(); float Ys = Y - oldY; float X = ev.getX(); int [] location = new int [2];
getLocationInWindow(location); //滑动到顶部让父控件重新获得触摸事件
if (Ys > 0 && currentPosition == 0) {
getParent().getParent().requestDisallowInterceptTouchEvent(false);
} break; case MotionEvent.ACTION_DOWN:
getParent().getParent().requestDisallowInterceptTouchEvent(true);
oldY = ev.getY();
oldX = ev.getX(); break; case MotionEvent.ACTION_UP:
getParent().getParent().requestDisallowInterceptTouchEvent(true); break; default: break;
} return super.onTouchEvent(ev);
} @Override
public void onScrollStateChanged(AbsListView view, int scrollState) {
currentPosition = getFirstVisiblePosition();
} @Override
public void onScroll(AbsListView view, int firstVisibleItem, int visibleItemCount, int totalItemCount) {
}
}NoScrollViewPager为最外层的父布局
当滑动到图文详情模块时, 能禁止掉ViewPager的滑动事件
大概意思就是滑动跟到了图文详情时不能直接向右滑动的方式切换到详情和评价模块(参照京东淘宝功能)
/**
* 提供禁止滑动功能的自定义ViewPager
*/public class NoScrollViewPager extends ViewPager { private boolean noScroll = false; public NoScrollViewPager(Context context, AttributeSet attrs) { super(context, attrs);
} public NoScrollViewPager(Context context) { super(context);
} public void setNoScroll(boolean noScroll) { this.noScroll = noScroll;
} @Override
public void scrollTo(int x, int y) { super.scrollTo(x, y);
} @Override
public boolean onTouchEvent(MotionEvent arg0) { if (noScroll) return false; else
return super.onTouchEvent(arg0);
} @Override
public boolean onInterceptTouchEvent(MotionEvent arg0) { if (noScroll) return false; else
return super.onInterceptTouchEvent(arg0);
} @Override
public void setCurrentItem(int item, boolean smoothScroll) { super.setCurrentItem(item, smoothScroll);
} @Override
public void setCurrentItem(int item) { super.setCurrentItem(item);
}
}商品模块最外层的布局是一个自定义的ViewGroup名为
SlideDetailsLayoutSlideDetailsLayout内容有两个View,mFrontView(第一个View)和mBehindView(第二个View)
有两种状态, 状态设置为close就显示第一个商品数据View, open状态就显示第二个图文详情View
@SuppressWarnings("unused")public class SlideDetailsLayout extends ViewGroup { /**
* Callback for panel OPEN-CLOSE status changed.
*/
public interface OnSlideDetailsListener { /**
* Called after status changed.
*
* @param status {@link Status}
*/
void onStatucChanged(Status status);
} public enum Status { /** Panel is closed */
CLOSE, /** Panel is opened */
OPEN; public static Status valueOf(int stats) { if (0 == stats) { return CLOSE;
} else if (1 == stats) { return OPEN;
} else { return CLOSE;
}
}
} private static final float DEFAULT_PERCENT = 0.2f; private static final int DEFAULT_DURATION = 300; private View mFrontView; private View mBehindView; private float mTouchSlop; private float mInitMotionY; private float mInitMotionX; private View mTarget; private float mSlideOffset; private Status mStatus = Status.CLOSE; private boolean isFirstShowBehindView = true; private float mPercent = DEFAULT_PERCENT; private long mDuration = DEFAULT_DURATION; private int mDefaultPanel = 0; private OnSlideDetailsListener mOnSlideDetailsListener; public SlideDetailsLayout(Context context) { this(context, null);
} public SlideDetailsLayout(Context context, AttributeSet attrs) { this(context, attrs, 0);
} public SlideDetailsLayout(Context context, AttributeSet attrs, int defStyleAttr) { super(context, attrs, defStyleAttr);
TypedArray a = context.obtainStyledAttributes(attrs, R.styleable.SlideDetailsLayout, defStyleAttr, 0);
mPercent = a.getFloat(R.styleable.SlideDetailsLayout_percent, DEFAULT_PERCENT);
mDuration = a.getInt(R.styleable.SlideDetailsLayout_duration, DEFAULT_DURATION);
mDefaultPanel = a.getInt(R.styleable.SlideDetailsLayout_default_panel, 0);
a.recycle();
mTouchSlop = ViewConfiguration.get(getContext()).getScaledTouchSlop();
} /**
* Set the callback of panel OPEN-CLOSE status.
*
* @param listener {@link OnSlideDetailsListener}
*/
public void setOnSlideDetailsListener(OnSlideDetailsListener listener) { this.mOnSlideDetailsListener = listener;
} /**
* Open pannel smoothly.
*
* @param smooth true, smoothly. false otherwise.
*/
public void smoothOpen(boolean smooth) { if (mStatus != Status.OPEN) {
mStatus = Status.OPEN; final float height = -getMeasuredHeight();
animatorSwitch(0, height, true, smooth ? mDuration : 0);
}
} /**
* Close pannel smoothly.
*
* @param smooth true, smoothly. false otherwise.
*/
public void smoothClose(boolean smooth) { if (mStatus != Status.CLOSE) {
mStatus = Status.CLOSE; final float height = -getMeasuredHeight();
animatorSwitch(height, 0, true, smooth ? mDuration : 0);
}
} /**
* Set the float value for indicate the moment of switch panel
*
* @param percent (0.0, 1.0)
*/
public void setPercent(float percent) { this.mPercent = percent;
} @Override
protected LayoutParams generateDefaultLayoutParams() { return new MarginLayoutParams(MarginLayoutParams.WRAP_CONTENT, MarginLayoutParams.WRAP_CONTENT);
} @Override
public LayoutParams generateLayoutParams(AttributeSet attrs) { return new MarginLayoutParams(getContext(), attrs);
} @Override
protected LayoutParams generateLayoutParams(LayoutParams p) { return new MarginLayoutParams(p);
} @Override
protected void onFinishInflate() { super.onFinishInflate(); final int childCount = getChildCount(); if (1 >= childCount) { throw new RuntimeException("SlideDetailsLayout only accept childs more than 1!!");
}
mFrontView = getChildAt(0);
mBehindView = getChildAt(1); // set behindview's visibility to GONE before show.
//mBehindView.setVisibility(GONE);
if(mDefaultPanel == 1){
post(new Runnable() { @Override
public void run() {
smoothOpen(false);
}
});
}
} @Override
protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) { final int pWidth = MeasureSpec.getSize(widthMeasureSpec); final int pHeight = MeasureSpec.getSize(heightMeasureSpec); final int childWidthMeasureSpec =
MeasureSpec.makeMeasureSpec(pWidth, MeasureSpec.EXACTLY); final int childHeightMeasureSpec =
MeasureSpec.makeMeasureSpec(pHeight, MeasureSpec.EXACTLY);
View child; for (int i = 0; i < getChildCount(); i++) {
child = getChildAt(i); // skip measure if gone
if (child.getVisibility() == GONE) { continue;
}
measureChild(child, childWidthMeasureSpec, childHeightMeasureSpec);
}
setMeasuredDimension(pWidth, pHeight);
} @Override
protected void onLayout(boolean changed, int l, int t, int r, int b) { final int left = l; final int right = r; int top; int bottom; final int offset = (int) mSlideOffset;
View child; for (int i = 0; i < getChildCount(); i++) {
child = getChildAt(i); // skip layout
if (child.getVisibility() == GONE) { continue;
} if (child == mBehindView) {
top = b + offset;
bottom = top + b - t;
} else {
top = t + offset;
bottom = b + offset;
}
child.layout(left, top, right, bottom);
}
} @Override
public boolean onInterceptTouchEvent(MotionEvent ev) {
ensureTarget(); if (null == mTarget) { return false;
} if (!isEnabled()) { return false;
} final int aciton = MotionEventCompat.getActionMasked(ev); boolean shouldIntercept = false; switch (aciton) { case MotionEvent.ACTION_DOWN: {
mInitMotionX = ev.getX();
mInitMotionY = ev.getY();
shouldIntercept = false; break;
} case MotionEvent.ACTION_MOVE: { final float x = ev.getX(); final float y = ev.getY(); final float xDiff = x - mInitMotionX; final float yDiff = y - mInitMotionY; if (canChildScrollVertically((int) yDiff)) {
shouldIntercept = false;
} else { final float xDiffabs = Math.abs(xDiff); final float yDiffabs = Math.abs(yDiff); // intercept rules：
// 1. The vertical displacement is larger than the horizontal displacement;
// 2. Panel stauts is CLOSE：slide up
// 3. Panel status is OPEN：slide down
if (yDiffabs > mTouchSlop && yDiffabs >= xDiffabs
&& !(mStatus == Status.CLOSE && yDiff > 0
|| mStatus == Status.OPEN && yDiff < 0)) {
shouldIntercept = true;
}
} break;
} case MotionEvent.ACTION_UP: case MotionEvent.ACTION_CANCEL: {
shouldIntercept = false; break;
}
} return shouldIntercept;
} @Override
public boolean onTouchEvent(MotionEvent ev) {
ensureTarget(); if (null == mTarget) { return false;
} if (!isEnabled()) { return false;
} boolean wantTouch = true; final int action = MotionEventCompat.getActionMasked(ev); switch (action) { case MotionEvent.ACTION_DOWN: { // if target is a view, we want the DOWN action.
if (mTarget instanceof View) {
wantTouch = true;
} break;
} case MotionEvent.ACTION_MOVE: { final float y = ev.getY(); final float yDiff = y - mInitMotionY; if (canChildScrollVertically(((int) yDiff))) {
wantTouch = false;
} else {
processTouchEvent(yDiff);
wantTouch = true;
} break;
} case MotionEvent.ACTION_UP: case MotionEvent.ACTION_CANCEL: {
finishTouchEvent();
wantTouch = false; break;
}
} return wantTouch;
} /**
* @param offset Displacement in vertically.
*/
private void processTouchEvent(final float offset) { if (Math.abs(offset) < mTouchSlop) { return;
} final float oldOffset = mSlideOffset; // pull up to open
if (mStatus == Status.CLOSE) { // reset if pull down
if (offset >= 0) {
mSlideOffset = 0;
} else {
mSlideOffset = offset;
} if (mSlideOffset == oldOffset) { return;
} // pull down to close
} else if (mStatus == Status.OPEN) { final float pHeight = -getMeasuredHeight(); // reset if pull up
if (offset <= 0) {
mSlideOffset = pHeight;
} else { final float newOffset = pHeight + offset;
mSlideOffset = newOffset;
} if (mSlideOffset == oldOffset) { return;
}
} // relayout
requestLayout();
} /**
* Called after gesture is ending.
*/
private void finishTouchEvent() { final int pHeight = getMeasuredHeight(); final int percent = (int) (pHeight * mPercent); final float offset = mSlideOffset; boolean changed = false; if (Status.CLOSE == mStatus) { if (offset <= -percent) {
mSlideOffset = -pHeight;
mStatus = Status.OPEN;
changed = true;
} else { // keep panel closed
mSlideOffset = 0;
}
} else if (Status.OPEN == mStatus) { if ((offset + pHeight) >= percent) {
mSlideOffset = 0;
mStatus = Status.CLOSE;
changed = true;
} else { // keep panel opened
mSlideOffset = -pHeight;
}
}
animatorSwitch(offset, mSlideOffset, changed);
} private void animatorSwitch(final float start, final float end) {
animatorSwitch(start, end, true, mDuration);
} private void animatorSwitch(final float start, final float end, final long duration) {
animatorSwitch(start, end, true, duration);
} private void animatorSwitch(final float start, final float end, final boolean changed) {
animatorSwitch(start, end, changed, mDuration);
} private void animatorSwitch(final float start, final float end, final boolean changed, final long duration) {
ValueAnimator animator = ValueAnimator.ofFloat(start, end);
animator.addUpdateListener(new ValueAnimator.AnimatorUpdateListener() { @Override
public void onAnimationUpdate(ValueAnimator animation) {
mSlideOffset = (float) animation.getAnimatedValue();
requestLayout();
}
});
animator.addListener(new AnimatorListenerAdapter() { @Override
public void onAnimationEnd(Animator animation) { super.onAnimationEnd(animation); if (changed) { if (mStatus == Status.OPEN) {
checkAndFirstOpenPanel();
} if (null != mOnSlideDetailsListener) {
mOnSlideDetailsListener.onStatucChanged(mStatus);
}
}
}
});
animator.setDuration(duration);
animator.start();
} /**
* Whether the closed pannel is opened at first time.
* If open first, we should set the behind view's visibility as VISIBLE.
*/
private void checkAndFirstOpenPanel() { if (isFirstShowBehindView) {
isFirstShowBehindView = false;
mBehindView.setVisibility(VISIBLE);
}
} /**
* When pulling, target view changed by the panel status. If panel opened, the target is behind view.
* Front view is for otherwise.
*/
private void ensureTarget() { if (mStatus == Status.CLOSE) {
mTarget = mFrontView;
} else {
mTarget = mBehindView;
}
} /**
* Check child view can srcollable in vertical direction.
*
* @param direction Negative to check scrolling up, positive to check scrolling down.
*
* @return true if this view can be scrolled in the specified direction, false otherwise.
*/
protected boolean canChildScrollVertically(int direction) { if (mTarget instanceof AbsListView) { return canListViewSroll((AbsListView) mTarget);
} else if (mTarget instanceof FrameLayout ||
mTarget instanceof RelativeLayout ||
mTarget instanceof LinearLayout) {
View child; for (int i = 0; i < ((ViewGroup) mTarget).getChildCount(); i++) {
child = ((ViewGroup) mTarget).getChildAt(i); if (child instanceof AbsListView) { return canListViewSroll((AbsListView) child);
}
}
} if (android.os.Build.VERSION.SDK_INT < 14) { return ViewCompat.canScrollVertically(mTarget, -direction) || mTarget.getScrollY() > 0;
} else { return ViewCompat.canScrollVertically(mTarget, -direction);
}
} protected boolean canListViewSroll(AbsListView absListView) { if (mStatus == Status.OPEN) { return absListView.getChildCount() > 0
&& (absListView.getFirstVisiblePosition() > 0 || absListView.getChildAt(0)
.getTop() <
absListView.getPaddingTop());
} else { final int count = absListView.getChildCount(); return count > 0
&& (absListView.getLastVisiblePosition() < count - 1
|| absListView.getChildAt(count - 1)
.getBottom() > absListView.getMeasuredHeight());
}
} @Override
protected Parcelable onSaveInstanceState() {
SavedState ss = new SavedState(super.onSaveInstanceState());
ss.offset = mSlideOffset;
ss.status = mStatus.ordinal(); return ss;
} @Override
protected void onRestoreInstanceState(Parcelable state) {
SavedState ss = (SavedState) state; super.onRestoreInstanceState(ss.getSuperState());
mSlideOffset = ss.offset;
mStatus = Status.valueOf(ss.status); if (mStatus == Status.OPEN) {
mBehindView.setVisibility(VISIBLE);
}
requestLayout();
} static class SavedState extends BaseSavedState { private float offset; private int status; /**
* Constructor used when reading from a parcel. Reads the state of the superclass.
*
* @param source
*/
public SavedState(Parcel source) { super(source);
offset = source.readFloat();
status = source.readInt();
} /**
* Constructor called by derived classes when creating their SavedState objects
*
* @param superState The state of the superclass of this view
*/
public SavedState(Parcelable superState) { super(superState);
} @Override
public void writeToParcel(Parcel out, int flags) { super.writeToParcel(out, flags);
out.writeFloat(offset);
out.writeInt(status);
} public static final Creator<SavedState> CREATOR = new Creator<SavedState>() { public SavedState createFromParcel(Parcel in) { return new SavedState(in);
} public SavedState[] newArray(int size) { return new SavedState[size];
}
};
}
}这个商品详情页的架构也是本人在已上线的项目中使用
觉得实用的star一下, 谢谢大家
点击查看更多内容
为 TA 点赞
评论
共同学习，写下你的评论
评论加载中...
作者其他优质文章
正在加载中
感谢您的支持，我会继续努力的～
扫码打赏，你说多少就多少
赞赏金额会直接到老师账户
支付方式
打开微信扫一扫，即可进行扫码打赏哦
